BAOFENG BF-8000D Dual Band Radio | 10W
BAOFENG BF-8000D is a high-power 10W dual-band handheld radio, it's communication range...
Part Number: N/A
Product Inquiry Form
About the price
Due to the daily exchange rate and the customs tax of different countries, we do not disclose the price, please contact the online customer service, or send an Email to us, we will reply within 12 hours.
Send it to any country in the world
We support sending the goods to your freight forwarder in China, or we can send them to DHL, Fedex, UPS and other express companies.
100% New Original authentic
We are the gold agent of many Radio brands, as well as the factory of Radio accessories, we will provide the most cost-effective goods.
Description
x
BAOFENG BF-8000D is a high-power 10W dual-band handheld radio, it's communication range of up to 30km. The BF-8000D Radio is designed for amateur radio enthusiasts and professionals, providing reliable two-way communication resolution.
BF-8000D features a rugged, ergonomic design, Which makes it perfect for outdoor adventures, emergencies, and other outdoor activities. With dual-band functionality, it supports VHF/UHF frequencies and comes equipped with a long battery life for extended use.
Whether you're hiking, camping, or working in the field, the BF-8000D ensures clear, reliable communication, even in challenging environments.
General Specifications
| Overall Frequency Range | UHF: 136-174 MHz / 400-520 MHz |
| Channel Capacity | 128 |
| Channel Spacing | 25/12.5 kHz |
| Input Voltage | 7.4 VDC |
| Battery (Standard) | 9500mAh (Li-ion) |
| Battery Life (5-5-90, off power emission) | About 14 hours |
| Standby Current | ≤65mA |
| Receive Current | ≤450mA |
| Launch Current | ≤1.2A (High Power), 650mA (Low Power) |
| Frequency Stability | ±2.5ppm |
| Operating Temperature | -30°C to +60°C |
| Antenna Impedance | 50Ω |
| Walkie-Talkie Size (with battery, but without antenna) | 95 x 95 x 35mm |
| Walkie-Talkie Weight (including antenna and battery) | 195g |
Transmitting Part
| Transmitting Output Power | 10W |
| Modulation Method | 16K0F3E@25KHz, 11K0F3E@12.5KHz |
| Spurious Emission | -36dBm<1GHz, -30dBm>1GHz |
| FM Signal Ratio | 45dB@25KHz, 40dB@12.5KHz |
| Audio Distortion | ≤5% |
| Modulation Limit | ±5.0KHz@25KHz, ±2.5KHz@12.5KHz |
| Adjacent Channel Power | 70dB@25KHz, 60dB@12.5KHz |
| Audio Response (300-3000Hz) | +1~3dB |
Receiving Part
| Receive Sensitivity | 0.25≥v (12dB SINAD) |
| Adjacent Channel Selectivity | ≥60dB@25KHz, ≥55dB@12.5KHz |
| Intermodulation Immunity | ≥60dB@25KHz, ≥55dB@12.5KHz |
| Conducted Spurious Emission | ≤57dB@25KHz, ≤-57dB@12.5KHz |
| FM Signal-to-Noise Ratio | ≥45dB@25KHz, ≥40dB@12.5KHz |
| Audio Output Power | 0.5W @8 ohms |
| Audio Distortion | ≤5% |
| Audio Response (300-3000Hz) | +1~-3dB |
